Remlinger 2300 - Native Grass Seed Hopper Assembly Description - (Optional)

68 MAN-GD-2300-002
Native Grass Seed Hopper Assembly Description – (Optional)
7ft 10ft 15ft
Ref # Description Qt
y
Part # Qt
y
Part # Qt
y
Part #
1 Weldment, Hopper 1 RM-RR1585 1 RM-RR1369 2 RM-RR1585
2 Gasket, Rubber, NGS, Picker Wheel 12 RM-J8109 16 RM-J8109 24 RM-J8109
3 Rubber Seal Retain NGS 12 RM-RR1372 16 RM-RR1372 24 RM-RR1372
4 Rivet, Pop, 3/16 x 3.8, #66 48 RM-J1599 64 RM-J1599 96 RM-J1599
5 1” Center Bearin
g
FH205-16 Lock Col 1 RM-J0005 1 RM-J0005 2 RM-J0005
6 Flan
g
ette, 2 Hole, 205 bearin
g
2 RM-J00985 2 RM-J00985 4 RM-J00985
7 5/16”-18 x 1" C. Bolt 14 16 28
8 5/16” Lock Washer 14 16 28
9 5/16”-18 Hex Nu
t
14 16 28
10 Flan
g
ette, 2-hole, 204 bearin
g
12 RM-J0099 14 RM-J0099 24 RM-J0099
11 Bearin
g
, 1/2 sq.3/4 Flan
g
ette 3 RM-J8108 4 RM-J8108 6 RM-J8108
12 Picker Wheel Shaft Weldment 1 RM-RR1585 1 RM-RR1373 2 RM-RR1585
13 Picker Wheel NGS 12 RM-J8112 16 RM-J8112 24 RM-J8112
14 Meter, MGS, Housin
g
12 RM-J8110 16 RM-J8110 24 RM-J8110
15 1/4”-20 x 3/4" HCS 24 32 48
16 1/4” Lock Washer 24 32 48
17 1/4”-20 Hex Nu
t
24 32 48
18 Drive Shaft, A
g
itator 1 RM-RR1586 1 RM-RR1376 2 RM-RR1586
19 Bearin
g
, Self-
A
li
g
nin
g
, 3/4" 3 RM-J00062 3 RM-J00062 3 RM-J00062
20 Collar, Lockin
g
, 3/4 3 RM-J0053 3 RM-J0053 3 RM-J0053
21 5/16 Flat Washer 14 16 28
22 Weldment, A
g
itator Assembl
y
12 RM-RR1377 16 RM-RR1377 24 RM-RR1377
23 3/8”-16 x 1” HCS 12 16 24
24 40B Sprocket - 25 Tooth, 3/4" Ke
y
Bore 1 RM-J1638 1 RM-J1638 2 RM-J1638
25 Sprocket, 40B13, Hex Bore 2 RM-R6590 2 RM-R6590 3 RM-R6590
26 #40 Chain - 39 Links 1 RM-R124191 1 RM-R624191 1 RM-R624191
27 1/4" x 1" Ke
y
1 RM-E5915 1 RM-E5915 2 RM-E5915
28 Weldment, Hopper Lid 1 RM-RR1583 1 RM-RR1370 2 RM-RR1583
30 Slide Latch 1 RM-R6694 1 RM-R6694 2 RM-R6694
31 3/8”-16 x 1 1/2” HCS 2 2 4
32 3/8”-16 Hex Nu
t
24 32 48
33 3/8” Flat Washer 22 32 48
34 1/2” Flat Washer 4 4 8
35 1/2”-13 x 1 1/2” C. Bolt 2 2 4
36 1/2”-13 Lock Nu
t
22 4
37 Bracket Mountin
g
NGS 2 RM-RR1374 2 RM-RR1374 4 RM-RR1374
38 3/8” Lock Washer 20 20 40
39 Seed Tube Native Grass 12 RM-J7366 16 RM-J7366 24 RM-J7366
40 Weldment Native Grass Tube 12 RM-RR1366 16 RM-RR1366 24 RM-RR1366
41 Screw, Self-Drill, 1/4 - 14, 1 PLT 24 RM-J0501 32 RM-J0501 48 RM-J0501
42 Clamp, Hose, 1-13/16 x 2-3/4" 24 RM-J2321 32 RM-J2321 48 RM-J2321
43 40B15 Sprocket - .890 Hex Bore 1 RM-J1648 1 RM-J1648 1 RM-J1648
44 Sprocket, 40B33, .895 Hex 1 RM-RR1493 1 RM-RR1493 1 RM-RR1493
45 Sprocket, 40B48, Hex Bore 2 RM-R6589 2 RM-R6589 2 RM-R6589
46 Sprocket, 40B60, .895" Hex 1 RM-RR1492 1 RM-RR1492 1 RM-RR1492
47 #40 Chain Link Connector 5 RM-J1745 5 RM-J1745 5 RM-J1745
48 Inner Bushin
g
2 RM-R6733 2 RM-R6733 2 RM-R6733
49 Plastic Roller 1 RM-R6732 1 RM-R6732 1 RM-R6732
50
A
d
j
ustment Strap, Coulter Sprin
g
1 RM-R120285 1 RM-R120285 1 RM-R120285
51 Shield, NGS Hopper 1 RM-RR1384 1 RM-RR1384 1 RM-RR1384
53 Walk Board Support, rear wheel Left 3 RM-RR1494 3 RM-RR1494 4 RM-RR1494
54 3/4”-10 x 4” x 5 3/4" U-Bol
t
3 RM-J07148 3 RM-J07148 4 RM-J07148
56 #40 Chain - 89 Links 1 RM-R6697 1 RM-R6697 1 RM-R6697
57 3/8”-16 x 2 3/4” HCS 2 2 2
59 3/4” Lock Washer 6 6 8
60 3/4”-10 Hex Nu
t
66 8
