Remlinger 2300 - Gauge Wheel Assembly - 3 Point Drill

43 MAN-GD-2300-002
Gauge Wheel Assembly – 3 Point Drill
10’ & 15’ Drill Only
Ref. # Description Qt
y
Part #
1
A
rm Lift Wheel Ri
g
h
t
1 RM-RR1249
1
A
rm Lift Wheel Left 1 RM-RR1242
2
A
n
g
le Mountin
g
, Gau
g
e Wheel 2 RM-RR1244
3 Turnbuckle - 1-1/8”, NCX21-31 1 RM-J0905
4 1/2”-13 Lock Nu
t
1
5 Hub assembl
y
, 6 Bolt, 3000 # 1 RM-J72352
6 Rim, 6hole, 8 x 15, 4-5/8, Pilot 1 RM-J72783
7 Spindle, 6 Bolt, 3000#, 1.75” x 12” 1 RM-R305004
8 1/2”-13 x 3 1/4” HCS 1
9 Tire, 9.5LX15, 6 Pl
y
W/Tube 1 RM-J72545
10 1”-8 x 7 1/2” HCS 2
11 1”-8 Lock Nu
t
2
12 7/8”-9 x 7” x 6 1/2” U-Bolt 1 RM-J08373
13 Upper, 3 Point, Cat II 1 RM-S18456
14 7/16” L
y
nch Pin 1 RM-J15481
15 3/8” x 2 ½” Roll Pin 1 RM-J1513
16 7/8” Lock Washer 4
17 7/8”-9 Hex Nut 4
18 Bushin
g
, Pivot, Gau
g
e Wheel 1 RM-W20527
19 Spacer, 1.25OD x 1.03ID s 1.475 2 RM-M5112
20 7/8”-9 x 6” HCS 2
