Remlinger 2300 - Frame - Description

37 MAN-GD-2300-002
Frame – Description
7ft 10ft 15ft
Ref # Description Qt
y
Part # Qt
y
Part # Qt
y
Part #
1 Frame Weldment 1 RM-RR1551 1 RM-RR1360 1 RM-RR1540
2 Hex Jackshaft 1 RM-RR1274 1 RM-RR1273 1 RM-RR1547
3 Flan
g
ette 4 RM-J00985 4 RM-J00985 6 RM-J00985
4 Bearin
g
, 1", Center WL CLR 2 RM-J0005 2 RM-J0005 3 RM-J0005
5 3/8’-16 x 1” C. Bolt 2 2 2
6 3/8’-16 x 1 1/2” C. Bolt 6 6 6
7 3/8” Lock Washer 10 10 10
8 3/8”-16 Hex Nu
t
13 13 13
9 Meter, Acre 1 RM-J81135 1 RM-J81135 1 RM-J8116
10 Drive Wheel, Assembl
y
1 RM-RR1480 1 RM-RR1480 1 RM-RR1480
11 Shaft Collar, 1" 2 RM-J1335 2 RM-J1335 2 RM-J1335
12 19t Sprocket -.895 Hex Bore 1 RM-RR1490 1 RM-RR1490 1 RM-RR1490
13 Plastic Roller 2 RM-R6732 2 RM-R6732 2 RM-R6732
14 3/8’-16 x 2 3/4” C. Bolt 2 2 2
15 3/8” Flat Washer 11 11 11
16 Inner Bushin
g
2 RM-R6733 2 RM-R6733 2 RM-R6733
17 Shield Stand-off 3 RM-RR1327-01 3 RM-RR1327-01 3 RM-RR1327-01
18 3/8”-16 Hex Lock Nu
t
3 3 3
19 Sprocket, 40B13, .095” Hex 1 RM-R6590 1 RM-R6590 1 RM-R6590
20 Sprocket, 40B23, .895” Hex 1 RM-RR1491 1 RM-RR1491 1 RM-RR1491
21 Sprocket, 40B33, .895" Hex 1 RM-RR1493 1 RM-RR1493 1 RM-RR1493
22 Drill Chain Shield 1 RM-RR1327 1 RM-RR1327 1 RM-RR1327
23 3-Point Assembl
y
1 RM-RR1252 1 RM-RR1252 1 RM-RR1252
24 2055 Shield Cover 1 RM-RR1330 1 RM-RR1330 1 RM-RR1330
25 Rivet, Pop 3/16 3/8", #66 4 RM-J1599 4 RM-J1599 4 RM-J1599
26 Walk Board Weldmen
t
1 RM-RR1544 1 RM-RR1205 2 RM-RR1544
27 1/2” Flat Washer 8 8 14
28 1/2“-13 x 1 1/2 C. Bolt 2 2 4
29 1/2”-13 Hex Lock Nu
t
4 4 6
30 1/2”-13 x 1 3/4 HCS 1 1 2
31 1/2”-13 Hex Nu
t
2 2 4
32 Bracket Slide 1 RM-RR1137 1 RM-RR1137 2 RM-RR1137
33 1/2”-13 x 1 1/4 HCS 2 2 4
34 #40 Chain - 117 Links 1 RM-RR1336 1 RM-RR1336 1 RM-RR1336
35 SMV Bracke
t
1 RM-W2247 1 RM-W2247 1 RM-W2247
36 1/2” Lock Washer 1 1 1
37 SMV Si
g
n 1 RM-J2250 1 RM-J2250 1 RM-J2250
38 1/4”-20 x 3/4 HCS 2 2 2
39 1/4” Lock Washer 2 2 2
40 1/4”-20 Hex Nu
t
2 2 2
41 Shipping Stand Mounting
Bracke
t
1 RM-R1331 1 RM-R1331 1 RM-R1331
42 Parkin
g
Stand Weldmen
t
3 RM-R6604 3 RM-R6604 3 RM-R6604
43 Pin, Snapper 3 RM-J5431 3 RM-J5431 3 RM-J5431
44 Shield Guard 1 RM-RR1454 1 RM-RR1454 1 RM-RR1454
45 Sprocket Holder 1 RM-RR1338 1 RM-RR1338 1 RM-RR1338
46 Tube Holder Bracke
t
1 RM-RR1540-15 1 RM-RR1540-15 1 RM-RR1540-15
47 Manual Holder 1 RM-J73620 1 RM-J73620 1 RM-J73620
