39 MAN-GD-2300-002
Hopper Assembly – Description
7ft 10ft 15ft
Ref # Description Qt
Part # Qt
Part # Qt
Part #
1 Hopper Weldment 1 RM-RR11541 1 RM-RR1568 1 RM-RR1541
2 Meter Housin
, Assembl
12 RM-J8120 18 RM-J8120 24 RM-J8120
3 Hopper Lid Weldmen
1 RM-RR1542 1 RM-RR1203 2 RM-RR1542
4 Shaft, Meter 1 RM-RR1545 1 RM-RR1207 2 RM-RR1545
5 Bearin
, Flan
e, 1-1/4” W/Flan
ette 1 RM-J00901 1 RM-J00901 1 RM-J00901
6 Sprocket Drive Weldmen
1 RM-R6731 1 RM-R6731 1 RM-R6731
7 Spool, Meter, Ad
ustmen
1 RM-RR1101 1 RM-RR1101 1 RM-RR1101
8 Plate, Gau
e, Lever Ad
ustment 1 RM-L0845 1 RM-L0845 1 RM-L0845
9
rm, Ad
ustin
1 RM-RR1104 1 RM-RR1104 1 RM-RR1104
10 Bearin
, Cam Follower, .75 CF 3/4S 1 RM-J0035 1 RM-J0035 1 RM-J0035
11 Spacer, Medium Swivel 1 RM-RR1105 1 RM-RR1105 1 RM-RR1105
12 5/32” x 1” Roll Pin 1 RM-J1480 1 RM-J1480 1
13 3/8”-16 x 7/8” C. Bolt 3 3 3
14 1/2”-13 x 1 1/2” HCS 3 3 5
15 3/8”-24 Hex Nut - Fine Thread 1 1 1
16 1/2” Flat Washer 5 5 7
17 3/8”-16
d
ustment Handle 1 RM-J0039 1 RM-J0039 1 RM-J0039
18 1/2“-13 Lock Nu
55 7
19 12”-20” x 90lb Gas Sprin
1 RM-J0038 1 RM-J0038 2 RM-J0038
24 1/4” Flat Washer 26 38 54
25 1/4”-20 Hex Nu
22 4
29 3/8”-16 x 1” HCS 4 4 4
30 Nut, Hex, 3/8-16, PLT 6 6 6
31 3/8” Lock Washer 6 6 6
32 Latch Handle Assembl
1 RM-RR1140 1 RM-RR1140 1 RM-RR1140
33 1/4”-20 x 3/4” HCS 24 36 48
34 1/4”-20 Lock Nu
24 36 48
35 Collar, Lock, Krause Meter 12 RM-R6565 18 RM-R6565 24 RM-R6565
36 1/4”-20 x 1/2” Setscrew 12 RM-J1075 18 RM-J1075 24 RM-J1075
37 3/8” Flat Washer 2 2 2
39 Handle Weldment 1 RM-RR1543 1 RM-RR1278 2 RM-RR1543
41 5/16”-18 x 1” HCS 6 6 12
43 5/16” Lock Washer 6 6 12
44 5/16”-18 Hex Nut, He
66 12
45 Plu
, Meter, Hopper Bottom 2 RM-RR1122 2 RM-RR1122 --- -------
46 Center Drive Hub
5/8” Sq. --- ------- --- ------- 1 RM-RR1545-01
47 Outer Drive Hub
5/8” Sq. 1 RM-RR1545-02 1 RM-RR1545-02 1 RM-RR1545-02
