Remlinger 2300 - Hydraulic Components - Pull Type Drill

51 MAN-GD-2300-002
Hydraulic Components – Pull Type Drill
7FT 10FT 15FT
Ref # Description
Cylinder
Seal Kit
Qty Part # Qty Part # Qty Part #
1 C
y
linder, 3 x 8", W/ STP RM-J72021 1 RM-J71945 1 RM-J71945 --- ------
1 C
y
linder, 3.5 x 8", ASAE RM-J71073 --- ------ --- ------ 1 RM-J7107
2
Cylinder, 2.75" x 8",
RPHSNG, W/STP
RM-J71935 1 RM-J7193 1 RM-J7193 --- ------
2
Cylinder, 3 x 8", RPHSING,
W/ STP
RM-J72022 --- ------ --- ------ 1 RM-J71931
3
Cylinder, 2.5 x 8",
RPHSING, W/ Pins
RM-J720020 1 RM-J7174 1 RM-J7174 --- ------
3
Cylinder, 2.75 x 8",
RPHSNG, W/ Pins
RM-J71935 --- ------ --- ------ 1 RM-J71941
4
Elbow 90° 1/2MIP x 3/4 - 16MJIC, 1208
6 RM-J71021 6 RM-J71021 6 RM-J71021
5 Restrictor - 3/4" 2 RM-J71028 2 RM-J71028 2 RM-J71028
6 H
y
draulic Hose, 3/8" ID x 6' W/ Fittin
g
s 1 RM-S1905 1 RM-S1905 1 RM-S1905
7 H
y
draulic Hose, 3/8" ID x 5' W/ Fittin
g
s 1 RM-M3736 1 RM-M3736 1 RM-M3736
8 Hydraulic Hose, 3/8" ID x 19' 6" W/ Fittings 2
RM-
RR1469
--- ------ --- ------
H
y
draulic Hose, 3/8" ID x 21' W/ Fittin
g
s --- ------ 2 RM-G2212 --- ------
H
y
draulic Hose, 3/8" ID x 23' 6" W/ Fittin
g
s --- ------ --- ------ 2 RM-RR1557
9 H
y
draulic Hose, 3/8" ID 7.5' W/ Fittin
g
s 1 RM-M3442 --- ------ --- -------
H
y
draulic Hose, 3/8" ID x 10' 6" W/ Fittin
g
s --- ------ 1 RM-RR1515 --- ------
H
y
draulic Hose, 3/8" ID x 15' 6" W/ Fittin
g
s --- ------ --- ------ 1 RM-RR1556
