Small Seed Hopper Assembly – Description (Optional)
7ft 10ft 15ft
Ref # Description Qt
y
Part # Qt
y
Part # Qt
y
Part #
1 Small Hopper Weldment 1 RM-RR1548 1 RM-RR1302 2 RM-RR1548
2 Weldment, Lid, 1 RM-RR1549 1 RM-RR1304 2 RM-RR1549
3 3/8"16 x 1" C. Bolt 3 3 6
4 3/8” Flat Washer 12 12 24
5 3/8”-16 Hex Lock Nu
t
77 14
6 3/8”-16 x 1 1/4" HCS 2 2 4
7 3/8”-16 Hex Nu
t
44 8
8 6”-9 5/8” x 30lb Gas Sprin
g
1 RM-J0043 1 RM-J0043 2 RM-J0043
9 Plate, Gau
g
e, Lever Ad
j
ustment 1 RM-L0845 1 RM-L0845 1 RM-L0845
10 Rivet, Pop, 3/16 x 3/8, #66 2 RM-J1599 2 RM-J1599 2 RM-J1599
11
A
ssembl
y
, Grass Seed Meter 12 RM-R522449 18 RM-R522449 24 RM-R522449
12 1/4”-20 x 1/2” HCS 24 36 48
13 Meter Shaf
t
1 RM-RR1550 1 RM-RR1307 2 RM-RR1550
14 Spool,
A
d
j
ustment, Meter 1 RM-RR1119 1 RM-RR1119 1 RM-RR1119
15 1/4”-20 x 1/2" Hex Lock Nut 24 36 48
16 Shaft Collar - Modified 2 RM-M3709 2 RM-M3709 2 RM-M3709
17 Handle Meter Ad
j
ustmen
t
1 RM-RR1121 1 RM-RR1121 1 RR1121
18 Bearin
g
, .75, Cam Follower, CF 1 RM-J0035 1 RM-J0035 1 RM-J0035
19 3/8” Lock Washer 1 1 1
20 3/8”-24 UNF Hex Nut Fine Thread 1 1 1
21 Spacer, Medium Swivel 1 RM-RR1105 1 RM-RR1105 1 RM-RR1105
22 1/2”-13 x 1 1/2” HCS 1 1 1
23 1/2” Flat Washer 1 1 1
24 1/2”-13 Hex Lock Nu
t
11 1
25 3/8”-16 Ad
j
ustment Handle 2 RM-J0039 2 RM-J0039 2 RM-J0039
26 5/32” x 1” Roll Pin 1 RM-J1480 1 RM-J1480 1 RM-J1480
27 Bearin
g
, 1", Flan
g
e 1 RM-J0003 1 RM-J0003 1 RM-J0003
28 3/8”-16 x 1” HCS 2 2 2
29 Sprocket, Weldment, 47 Tooth 1 RM-RR1324 1 RM-RR1324 1 RM-RR1324
30 Latch Handle
A
ssembl
y
1 RM-RR1140 1 RM-RR1140 2 RM-RR1140
31 Small Seed Tube, Grass Seed 12 RM-J7363 18 RM-J7363 24 RM-J7363
32 Clamp, Seed Tube 12 RM-J7364 18 RM-J7364 24 RM-J7364
33 Grass Seed Tube 12 RM-RR1332 18 RM-RR1332 24 RM-RR1332
34 Hose Clamp 12 RM-J23192 18 RM-J23192 24 RM-J23192
35 5/16”-18 U-Bolt 12 RM-J0810 18 RM-J0810 24 RM-J0810
36 5/16”-18 Hex Lock Nut 24 36 48
37 5/16” Flat Washer 24 36 48
38 Plastic Roller 1 RM-R6732 1 RM-R6732 1 RM-R6732
39 Inner Bushin
g
1 RM-R6733 1 RM-R6733 1 RM-R6733
40 3/8"-16 x 2 1/2" C. Bolt 1 1 1
43 Grass Seeder Shield 1 RM-RR1328 1 RM-RR1328 1 RM-RR1328
44 #40 Chain - 99 Links 1 RM-R624188 1 RM-R624188 1 RM-R624188
45 #40 Chain Link Connector 1 RM-J1745 1 RM-J1745 1 RM-J1745
46 3/8"-16 x 4 1/2” C. Bolt 12 1 1
47 Weldment, Small Grass Seed Tube Holder 12 RM-RR1365 18 RM-RR1365 24 RM-RR1365
48 1/4”-20 x 1” HCS 24 36 48
