Remlinger 2300 - Lift Wheel Assembly - Pull Type Drill

42 MAN-GD-2300-002
Lift Wheel Assembly – Pull Type Drill
7ft 10ft 15ft
Ref # Description Qt
y
Part # Qt
y
Part # Qt
y
Part #
1 Lift Wheel Mount Weldment 2 RM-RR1477 2 RM-RR1477 2 RM-RR1477
2
A
rm Lift Wheel Weldment, Ri
g
h
t
1 RM-RR1249 1 RM-RR1249 -- ------
2
A
rm Lift Wheel Weldment, Left 1 RM-RR1242 1 RM-RR1242 -- ------
2
A
rm, Lift Wheel Weldment, Dual Wheels -- ------ -- ------ 2 RM-RR1603
3 C
y
linder - See H
y
draulic Components -- ----- -- ------ -- ------
4 Spindle, 5 bolt, Left & Ri
g
ht 2 RM-S15394 -- ------ -- ------
4 Spindle, 6 bolt, Left & Ri
g
ht -- ------ 2 RM-R305004 2 RM-R305004
5 Hub Assembly Complete, 5 Bolt (7Ft) Left &
Ri
g
h
t
1 RM-J7280 -- ------- -- ------
5 Hub Assembly Complete, 6 Bolt (10&15Ft)
Left & Ri
g
ht
-- ------ 2 RM-J72352 4 RM-J72352
6 Rim, Wheel, 15 x 5, 5 Bolt
(
7Ft
)
Left & Ri
g
ht 2 RM-J72775 -- ------ -- ------
6 Rim, Wheel, 15 x 8, 6 Bolt (10&15Ft) Left &
Ri
g
h
t
-- ------ 2 RM-J72783 4 RM-J72783
7 Tire, 9.5L - 15, 6-Pl
y
, Tube T
y
pe 2 RM-J72545 2 RM-J72545 4 RM-J72545
8 Pivot Bushin
g
2 RM-W20527 2 RM-W20527 2 RM-W20527
9 Spacer, 1-1/8" 4 RM-M5112 4 RM-M5112 4 RM-M5112
10 3/4”-10 x 4” x 5 3/4” U-Bolt 4 RM-J07148 4 RM-J07148 4 RM-J07148
11 Nut, Lock, 3/4 - 10 Grade B 8 RM-J1057 8 RM-J1057 8 RM-J1057
12 1”-8 x 7 1/2” HCS 4 4 4
13 1”-8 Lock Nu
t
44 4
14 1/2”-13 x 3 1/4” HCS 2 2 2
15 1/2”-13 Lock 2 2 2
16 Upper 3-pt Pin, Cat II 2 RM-S18456 2 RM-S18456 2 RM-S18456
17 7/16” L
y
nch Pin 2 RM-J15481 2 RM-J15481 2 RM-J15481
18 3/8” x 2 1/2” Roll Pin 2 2 2
19 Transport Lock Weldmen
t
2 RM-RR1519 2 RM-RR1519 2 RM-RR1519
