12B-53
TURBOCHARGING
Turbocharger outlet exhaust gas duct: Removal - Refitting
K9K, and 836
12B
a Remove the turbocharger air inlet pipe bolt from the
exhaust gas recirculation assembly (4) .
a Disconnect the oil vapour rebreathing pipe from the
rocker cover (5) .
a Remove:
-the turbocharger air inlet pipe bolts (6) from the tur-
bocharger,
- the turbocharger air inlet pipe.
a Remove:
- the bolts (7) from the bracket of the turbocharger
outlet exhaust gas duct,
- the bracket from the turbocharger outlet exhaust
gas duct.
