10A-81
ENGINE AND CYLINDER BLOCK ASSEMBLY
Oil pump: Removal - Refitting
F4R
10A
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Position the oil pump pinion on the chain.
a Refit the oil pump.
a Torque tighten the oil pump bolts (25 N.m).
a Refit the oil splash plate.
a Torque tighten the oil splash plate bolt (25 Nm).
II - FINAL OPERATION
a Refit:
-the sump (see 10A, Engine and cylinder block
assembly, Sump: Removal - Refitting, page
10A-25) ,
-the lower engine tie-bar (see 19D, Engine moun-
ting, Lower engine tie-bar: Removal - Refitting,
page 19D-33) .
a Fill up the engine oil (see 10A, Engine and cylinder
block assembly, Engine oil: Draining - Refilling,
page 10A-40) .
a Refit the engine undertray.
Note:
Ensure that the oil splash plate is correctly posi-
tioned.
