RH850/U2A 292pin 2. Jumpers, Connectors and LEDs
R20UT4970ED0101 Rev.1.01 Page 20 of 67
July 08, 2022
2.3 LED Overview
The following table provides an overview of all LED.
Table 2.3 LED overview
LED Function Color Remark
LED1 Device ERROROUT signal red
LED2 Signaling LED yellow connection via CN7,
refer to 6.3 Signaling LEDs
LED3 Signaling LED
LED4 Signaling LED
LED5 Signaling LED
LED6 Signaling LED
LED7 Signaling LED
LED8 Signaling LED
LED9 Signaling LED
LED10
1.12 V device core voltage
VDD
green
refer to 3.5 Power Supply
LEDs
LED11 5.0 V power supply P5V0 green
LED12 3.3 V power supply P3V3 green
LED13 Reset switch SW1 on red
LED14 Device VMONOUTZ signal red
LED15 Device PWRCTL signal red
