1. Overview
The RH850/U2A 292pin piggyback board is part of the RH850 Evaluation Platform and serves
as a simple and easy to use platform for evaluating the features and performance of Renesas
Electronics' 32-bit RH850/U2A 292pin microcontrollers.
Notes
1. This document describes the functionality of the piggyback board and guides the user through its
operation.
For details regarding the operation of the microcontroller, refer to the device's Hardware User’s Manual.
2. In this document low active signals are marked by an appended ‘Z’ to the pin or signal name. E.g. the
reset pin is named RESETZ.
3. In this document following abbreviations are used:
− H level, L level: high or low signal level of a digital signal, the absolute voltage value depends on the
signal
1.1 Package Components
The Y-RH850-U2A-292PIN-PB-T1-V2 product package consists of the following items. After
you have unpacked the box, check if your Y-RH850-U2A-292PIN-PB-T1-V2 package contains
all of these items.
Table 1.1 Package Components for the Y-RH850-U2A-292PIN-PB-T1-V2
shows the packing components of the Y-RH850-U2A-292PIN-PB-T1-V2 package.
Table 1.1 Package Components for the Y-RH850-U2A-292PIN-PB-T1-V2
Item
Description
Quantity
D018037
RH850/U2A 292pin
piggyback board
1
D018332
Documentation CD
1
D010816-24
China RoHS document
1
D010818-24 WEEE+CE document 1
D018037-24
Product contents List
1
Jumpers (2-way, 0.1”)
In the bag
44 (min. quantity)
Red Hirschmann 4 mm
power lab sockets
In the bag
3
Black Hirschmann 4 mm
power lab sockets
In the bag
1
Würth PCB Terminal Block
connector
In the bag
1
