RH850/U2A 292pin 7. Connectors
R20UT4970ED0101 Rev.1.01 Page 44 of 67
July 08, 2022
7.4.1 Device Ports Connector CN13
Pin Device port Pin Device port
1 AP0_4 2 AP0_0
3 AP0_6 4 AP0_2
5 AP0_8 6 AP1_3
7 AP0_1 8 AP1_2
9 AP0_3 10 AP1_1
11 AP0_5 12 AP1_0
13 AP0_7 14 AP0_15
15 AP0_13 16 AP0_14
17 AP0_9 18 AP0_12
19 AP0_11 20 AP0_10
21 P3_3 22 P3_2
23 P24_5 24 P24_4
25 P24_6 26 P24_7
27 P24_8 28 P24_9
29 P24_10 30 P24_11
31 P24_13 32 P24_12
33 P4_1 34 P4_0
35 P4_5 36 P4_4
37 P4_7 38 P4_6
39 P4_9 40 P4_8
41 P4_11 42 P4_10
43 P4_13 44 P4_12
