RH850/U2A 292pin 3. Power Supply
R20UT4970ED0101 Rev.1.01 Page 25 of 67
July 08, 2022
3.5 Power Supply LEDs
The following green LEDs indicate the presence of various voltages on the piggyback board:
• LED11 for 5.0 V power rail P5V0
• LED12 for 3.3 V power rail P3V3
• LED10 for 1.12 V device core voltage VDD
