Renesas RH850 User Manual

RH850/U2A 292pin 11. Schematics
R20UT4970ED0101 Rev.1.01 Page 57 of 67
July 08, 2022
11. Schematics
CAUTION
The schematics shown in this document are not intended to be used as a reference for mass
production. Any usage in an application design is in sole responsibility of the customer.
The following components described in the schematics are not provided with the board upon
delivery:
• Oscillators and resonators: OSC1, X3
• Capacitors: C60, C61, C97, C98
• Resistors: R2 – R4, R6, R15 – R18, R20, R21 – R23, R25, R143
The above components are indicated with "DNF/DNB" in the schematics.
The following components described in the schematics are provided with but not mounted on
the board upon delivery:
• 3 Hirschmann 4 mm power lab sockets, red for CN9 – CN11
• 1 Hirschmann 4 mm power lab sockets, black for CN8
• three resonators HC49 (16/20/24 MHz)
• 44 jumpers, 2.54 mm, black
The above components are indicated with "DO NOT FIT / TO DELIVER WITH THE BOARD"
in the schematics.
