Renesas RH850 User Manual

RH850/U2A 292pin 7. Connectors
R20UT4970ED0101 Rev.1.01 Page 43 of 67
July 08, 2022
Note
In order to minimize signal interference no signals from CN5 are connected to CN16. If required they can be
connected via 0 Ω resistors R15 to R18 and R21 to R23.
7.4 Device Ports Connectors CN13 to CN16
The device port connectors enable easy connection to almost all ports of the device.
CAUTION
The pin headers are directly connected to the pins, therefore special care must be taken to avoid any
electrostatic or other damage to the device.

Renesas RH850 Specifications

General

Memory Protection	Yes
CPU Cores	Single, Dual
Package	LQFP, BGA
Target Applications	Automotive, Industrial
Functional Safety	ISO 26262 ASIL-D compliant
Communication Interfaces	CAN, Ethernet, SPI, I2C, UART
