Renesas RH850 User Manual

RH850/U2A 292pin 7. Connectors
R20UT4970ED0101 Rev.1.01 Page 37 of 67
July 08, 2022
7.1.2 Main Board Connector CN2
Table 7.2 Main board connector CN2 (cont'd)
Pin Function Device port Pin Function Device port
1 CAN2TX P3_2 2 CAN3TX P4_4
3 CAN2RX P3_3 4 CAN3RX P4_5
5 CAN4TX P4_6 6 CAN5TX P4_11
7 CAN4RX P4_7 8 CAN5RX P4_12
9 LIN2TX P2_0 10 LIN3TX P4_14
11 LIN2RX P2_1 12 LIN3RX P4_15
13 LIN4TX P6_12 14 LIN5TX P2_2
15 LIN4RX P6_15 16 LIN5RX P2_3
17 LIN6TX P2_7 18 LIN7TX P3_5
19 LIN6RX P2_6 20 LIN7RX P3_4
21 LIN8TX P4_0 22 LIN9TX P5_3
23 LIN8RX P4_1 24 LIN9RX P5_2
25 LIN10TX P6_5 26 LIN11TX P3_8
27 LIN10RX P6_4 28 LIN11RX P3_7
29 LIN12TX ‒ 30 LIN13TX ‒
31 LIN12RX ‒ 32 LIN13RX ‒
33 LIN14TX ‒ 34 LIN15TX ‒
35 LIN14RX ‒ 36 LIN15RX ‒
37 ‒ ‒ 38 ‒ ‒
39 CAN12TX P24_10 40 CAN13TX P24_12
41 CAN12RX P24_11 42 CAN13RX P24_13
43 CAN14TX P17_3 44 CAN15TX P17_5
45 CAN14RX P17_4 46 CAN15RX P17_6
47 CAN6TX P4_14 48 CAN7TX P3_4
