RZ/A2M SUB Board RTK79210XXB00000BE 2. Function specifications
R20UT4398EJ0100 Rev.1.00 2-11
2018.10.11
Table 2.2.10 List of RZ/A2M Pin Function Selections Used on the RTK79210XXB00000BE (10)
P0_3 / D3 / DRP27 /
DV0_DATA20 / MTIOC7A /
GTIOC6A
Connects to DRP connector (CN2)
P6_6 / CS2 / DRP02 /
LCD0_TCON4 / DREQ0 /
CC1_RA0
Connects to DRP connector (CN2)
Connects to LED1 (red) on the CPU
board
P7_0 / WE1/DQMU / DRP04
/ DV0_CLK / SCK1 /
CC1_RD1
Connects to DRP connector (CN2)
PJ_3 / TRACEDATA1 /
NAF0 / VRAMMON3 /
RTS1 / SSIFS3
Connects to UDI connector (CN5 on
the CPU board)
PJ_1 / TRACECTL /
SPDIF_IN / VRAMMON1 /
RxD1 / VBUSIN0 / IRQ0
Connects to IRQ0 switch (SW3)
Connects to Ethernet PHY1 (U27)
Connects to Ethernet PHY2 (U28)
P0_6 / D6 / DRP30 /
DV0_DATA23 / MTIOC7D /
GTIOC7B
Connects to DRP connector (CN2)
PJ_2 / TRACEDATA0 /
FCE / VRAMMON2 / TxD1 /
SSITxD3
Connects to UDI connector (CN5 on
the CPU board)
P6_5 / CS3 / DRP01 /
LCD0_TCON5 /
AUDIO_XOUT / CC1_RD0
Connects to DRP connector (CN2)
PG_3 / ET0_COL /
VIO_D11 / SSL00 /
MTIOC3D / GTIOC0B
Connects to CMOS camera connector
(CN17)
P6_4 / CS5 / DRP00 /
LCD0_TCON6 /
AUDIO_CLK / SD1_CD
Connects to DRP connector (CN2)
Connects to Audio oscillator (X1)
PH_6 / HM_INT# / NAF3 /
ET1_WOL / MTIC5V / IRQ4
Connects to Ethernet PHY2 (U28)
[Note] : 3.3V power source, : 1.8V power source, : 1.2V power source, : 3.3V or 1.8V power source,
: GND
Red text CPU board setting display.
