Renfert POWER - 7 Troubleshooting; 8 Technical data; 8.1 Filter unit; 8.2 Flowmeter

en
7 Troubleshooting
Errors Cause Corrective action
POWER steamer is not
lled.
• Water connections assembled
againstthedirectionofowonthe
lterhead.
• Check the assembly of the water connections� The
directionofowisindicatedonthelterheadandthe
sensor unit�
• Watersupplyisturnedo󰀨. • Turn on the water supply�
A negative value is
shown when the "Filter
status" (Chap. 5.2.2) is
displayed.
• Theltercapacitywasnotreset
(seeChap.5.2.3)thelasttimethe
lterwasreplaced.
• Resettheltercapacity(seeChap.5.2.3).
Notes:
Iftheltercartridgethenremainsinoperationuntilthe
lterreplacementdisplayisshown,thismaybeconsi-
derablylongerthanintendedfortheltercartridge.If
necessary,replacetheltercartridgewithanewone
beforethelterreplacementdisplayisshown.
8 Technical data
8.1 Filter unit
Item no.
1846 0100
+ 1846 0103
1846 0100
+ 1846 0104
Dimensions
Height of the entire system / mm [inch] 475 [18�7] 410 [16�1]
Heightoftheltercartridge/mm[inch] 425 [16�7] 360 [14�2]
Diameteroftheltercartridges/mm[inch] 95 [3�7] 136 [5�6]
Minimumdistancetotheoor/mm[inch] 40 [1�6] 40 [1�6]
Weightoftheltercartridge/kg[lbs] 1�8 [4�0] 3�2 [7�1]
Operating data
Systempressure(withoutpressuresurges)/hPa(bar)[psi] 2000-8000(2-8)[29-116]
Water temperature / ambient temperature / °C [°F] 4 - 30 [39 - 86]
8.2 Flowmeter
Item no. 1846 0101
Sensor unit
Connection thread Inlet 3/8" BSP IG / Outlet 3/8" BSP AG
Inletpressure(min/max)/hPa(bar)[psi] 1000-8000(1-8)[14.5-116]
Flow range / l/h [gal/l] 15 - 500 [3�96 - 132]
Pressureloss/hPa(bar)[psi] ≤500(0.5)[7.25]
Measurement(horizontalinstallation)/% +/- 5
Watertemperature(min/max)/°C[°F] 4 - 30 [37�4 - 86]
Ambienttemperature(min/max)/°C[°F] 4 - 40 [37�4 - 104]
Dimensions(WxHxD)/mm[inch] 80 x 39 x 42 [3�15 x 1�54 x 1�65]
Installation position Horizontal recommended
Programming and display unit
Graphic display 5 digits in liters and gallons
Counter Decreasing from 99999 to -9999
Dimensions(WxHxD)/mm[inch] 80 x 54 x 29 [3�15 x 2�13 x 1�14]
Power supply, battery type 2 x AA
This unit corresponds to Part 15 of the FCC Rules�
Operation is subject to the following two conditions:
(1)Thisunitmaynotcauseharmfulinterferenceand
(2)Thisunitmustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired
operation�
The label with the FCC ID and logo is located inside the battery compartment�
- 13 -
