OMP40-2 installation guide
2.6
OMP40-2 basics
Principal application Workpiece inspection and job set-up on small to medium machining
centres and small multi-tasking machines.
Dimensions Length
Diameter
50mm (1.97 in)
40mm (1.57 in)
Weight (without shank) With batteries
Without batteries
250 g (8.82 oz)
234 g (8.25 oz)
Transmission type 360° infrared optical transmission (modulated or legacy)
Switch-on method Optical on
Switch-off methods Optical off or Timer off
Spindle speed (maximum) 1000 rev/min
Operating range Up to 5 m (16.4 ft)
Compatible receiver/
interface
Modulated
OMM-2 or OMM-2C with
OSI or OSI-D or with
OMI-2 / OMI-2T / OMI-2H
/ OMI-2C
Legacy
OMI / OMM with MI 12
Sense directions ±X, ±Y, +Z
Unidirectional repeatability 1.00 µm (40 µin) 2s (see note 1)
Stylus trigger force
(see notes 2 and 3)
XY low force
XY high force
Z
0.50 N, 51 gf (1.80 oz)
0.90 N, 92 gf (3.24 oz)
5.85 N, 597 gf (21.04 oz)
Stylus overtravel XY plane
+Z plane
±12.5°
6 mm (0.24 in)
Environment IP rating IPX8, BS EN 60529:1992+A2:2013
IK rating (OMP40-2 and
OMP40-2 LS)
IK01, BS EN 62262:2002+A1:2021
[for glass window]
IK rating (OMP40M) IK02, BS EN 62262:2002+A1:2021
[for glass window]
Storage temperature –25 °C to +70 °C (–13 °F to +158 °F)
Operating temperature +5 °C to +55 °C (+41 °F to +131 °F)
Battery types 2 x ½AA 3.6 V lithium-thionyl chloride (LTC)
Battery reserve life Approximately one week after a low battery warning is first given
(based on 5% usage).
Typical battery life See page 2.7
Note 1 Performance specification is tested at a standard test velocity of 480 mm/min (18.9 in/min) with a 50 mm stylus.
Significantly higher velocity is possible depending on application requirements.
Note 2 Trigger force, which is critical in some applications, is the force exerted on the component by the stylus when the
probe triggers. The maximum force applied will occur after the trigger point (overtravel). The force value depends
on related variables, including measuring speed and machine deceleration.
Note 3 These are the factory settings; manual adjustment is not possible.
OMP40-2 specification
