OMP40-2 installation guide
4.2
Trigger Logic
Factory
settings
New
settings
Switch-on method Optical Switch-on

Switch-off method Optical off

Short timeout (12 s)
Medium timeout (33 s)
Long timeout (134 s)
Enhanced trigger
filter
Off (0 ms)

On (10 ms)
Optical transmission
method
Legacy (start filter off)
Legacy (start filter on)
Modulated PROBE 1

Modulated PROBE 2
Modulated PROBE 3
Optical power Low
Standard

Ultra low
OMP40-2 serial no ........................................
 tick
Probe settings record
This page is provided to note your probe’s settings.
Factory settings are for kit A-4071-2001 only.
