Renishaw OMP400 User Manual

OMP400 installation guide
3.2
System installation
Performance envelope with an OMI-2T / OMI-2H / OMI-2 (modulated transmission)
OMP400
OMI-2T /
OMI-2H /
OMI-2
0°
Optical
centre line
60°
45°
45°
15°
30°
30°
15°
60°
0°
60°
45°
45°
15°
30°
30°
15°
60°
75°
4 (13.1)
3 (9.8)
2 (6.5)
1
(3.3)
5 (16.4)
4 (13.1)
3 (9.8)
2 (6.5)
1
(3.3)
5 (16.4)
75°
75°
75°
Typical plot at 20 °C (68 °F)
360° transmission around
probe axis in metres (feet)
Switch on/off
Operating - standard power mode
Operating - low power mode
