3.5
System
installation
Performance envelope with an OMM (legacy transmission)
0°
OMP400
60°
45°
45°
15°
30°
30°
75°
15°
60°
OMM
0°
60°
45°
45°
15°
30°
30°
75°
15°
60°
4 (13.1)
3 (9.8)
2 (6.6)
1
(3.3)
5 (16.4)
4 (13.1)
3 (9.8)
2 (6.6)
1
(3.3)
5 (16.4)
75°
75°
Typical plot at 20 °C (68 °F)
360° transmission around
probe axis in metres (feet)
Optical
centre line
Switch on/off
Operating - standard power mode
Operating - low power mode
