3.11
System
installation
NOTE: The stored radii values are based on the true electronic trigger points. These values are
different from the physical sizes.
Calibrating the probe length
Calibrating a probe on a known reference surface determines the length of the probe, based on the
electronic trigger point. The stored value for length is different from the physical length of the probe
assembly. Additionally, the operation can automatically compensate for machine and fixture height
errors by adjusting the probe length value that is stored.
