OMP400 installation guide
4.2
Trigger Logic™
Factory
settings
New
settings
Switch on method Optical on (standard)
Optical on (3 second delay)
Switch off method Optical off
Short timeout (12 s)
Medium timeout (33 s)
Long timeout (134 s)
Enhanced trigger filter
setting and spindle
orientation capability
Auto-reset off/filter on (8 ms)
Auto-reset off/filter on (16 ms)
Auto-reset on/filter on (8 ms)
Auto-reset on/filter on (16 ms)
Auto-reset off/Filter off
Optical transmission
type
Legacy (start filter off)
Legacy (start filter off)
Modulated (PROBE 1)
Modulated (PROBE 2)
Optical power setting Low power
Standard power
OMP400 serial no ........................................
tick
Probe settings record
This page is provided to note your probe's settings.
tick
To Next Page
