OMP400 installation guide
7.2
Parts list
Type Part number Description
Battery P-BT03-0007 1/2 AA battery (pack of 2).
Stylus A-5003-7306 50 mm long carbon bre with Ø6 mm ball.
Stylus A-5003-6510 100 mm long carbon bre with Ø6 mm ball.
Stylus A-5003-6511 150 mm long carbon bre with Ø6 mm ball.
Stylus A-5003-6512 200 mm long carbon bre with Ø6 mm ball.
Tool kit A-4071-0060
Probe tool kit comprising Ø1.98 mm stylus tool,
2.0 mm AF hexagon key and shank grub screw (x 6).
Mounting bracket A-2033-0830
OMM / OMI / OMI-2 mounting bracket with xing screws,
washers and nuts.
Software -
Probe software for machine tools - see data sheet
(H-2000-2289).
Shank adaptor
assembly
A-4071-0031
Adaptor assembly for mounting to MP10, MP12, MP700
type shanks.
Battery cassette A-4071-1166 Battery cassette kit.
Gasket A-4038-0301 OMP400 battery cap gasket.
MI 12 A-2075-0142 MI 12 interface unit.
MI12-B A-2075-0141 MI 12 interface panel mount kit.
Panel mount kit A-2033-0690 MI 12 interface panel mount kit.
OMM A-2033-0576
OMM complete with cable Ø4.85 mm x 25 m
(Ø0.19 in x 82 ft).
OMI A-2115-0001
OMI complete with cable Ø4.75 mm x 8 m
(Ø0.18 in x 26.25 ft).
OMI-2 A-5191-0049 OMI-2 complete with cable 8 m (26.25 ft) long.
OMI-2T A-5439-0049 OMI-2T complete with cable 8 m (26.25 ft) long.
Styli tool M-5000-3707 Tool for tightening / releasing styli.
Adaptor A-5069-0720 MP700 to OMP400 adaptor.
