Full XL system contents (additional items)
Index Part number Part name Includes Part number Index
8 A-8003-0665 Squareness measurement optics
Optical square 8A
Bracket squareness optic M-8003-1680 8B
Cap head screw (× 4) 8C
Hexagonal key 8E
9 A-8003-0442 Flatness measurement kit
Flatness mirror (× 2) A-8003-0630 9A
Base (150 mm) A-8003-0256 9B
Base (100 mm) A-8003-0257 9C
Base (50 mm) A-8003-0258 9D
10 A-8003-4270 Long range linear accessory kit
Long-range retroreector A-8003-2061 10A
Periscope A-8003-2039 10B
Long-range target M-8003-2081 10C
Clamp screw (× 2) M-8003-0221 10D
11 A-8003-0447 Optics mounting kit
Clamp block (× 2) A-8003-0262 11A
Base plate (× 2) A-8003-0522 11B
Mounting pillar (× 3) M-8003-0470 11C
M8 adaptor A-8003-0979 11D
12 A-8003-4209 Universal (straightness) shutter 12
13 A-8003-0560 Vertical turning mirror 13
14 A-8003-0604 Large straightness retroreector 14
15 A-8003-0576 Straightness base 15
16 A-8003-1304 Swivel mirror 16
17 A-8003-3072 Laser beam steerer LS350 17
18 A-8003-1325 Fixed turning mirror 18
19 A-9908-0780 Magnetic base 19
20 A-9908-0760 XL magnetic base adaptor 20
XL-80 Hardware

Renishaw XL-80 Specifications

General

Wavelength	633 nm
Linear measurement accuracy	±0.5 ppm
Maximum range	80 m
Linear Resolution	1 nm
Operating temperature range	0°C to 40°C
Laser Class	Class 2
Angular Resolution	0.01 arc sec
Straightness Resolution	0.01 μm
Humidity	0% to 95% non-condensing
Interferometer Type	Michelson interferometer
Resolution	0.001 µm
Environmental Compensation	Automatic
Air Pressure	650 mbar - 1150 mbar
Measurement Speed	4 m/s
Interface	USB
Power Supply	100-240V AC, 50-60Hz
