Then the array of XW, YW and MW will be as follows:
XW Allocated for register Modbus Slave register address
0 FL010 (XW0000) 440001
1 FLD0808R (XW0100) 440002
2 FLD0808N (XW0300) 440003
3 FLD1600 (XW0400) 440004
4 FLD1600 (XW0401) 440005
5 FLA0800L (XW0500) 440006
6 FLA0800L (XW0501) 440007
7 FLA0800L (XW0502) 440008
8 FLA0800L (XW0503) 440009
9 FLA0800L (XW0504) 440010
10 FLA0800L (XW0505) 440011
11 FLA0800L (XW0506) 440012
12 FLA0800L (XW0507) 440013
13 Not used
…. Not used
399 Not used
YW Allocated for register Modbus Slave register address
0 FL010 (YW0000) 441001
1 FLD0808R (YW0100) 441002
2 FLD0016R (YW0200) 441003
3 FLD0808N (YW0300) 441004
4 Not used
…. Not used
…. Not used
399 Not used
MW Allocated for register Modbus Slave register address
0 to 59 FL010 (MW0000 to MW0059) 460001 to 460060
60 to 109 FLA0800L (MW0500 to MW0549) 460061 to 460110
110 Not used
…. Not used
…. Not used
1599 Not used
To Next Page
