Troubleshooting
125
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
Register / Coil Tag Name Read / Write Description
S0022 COM2 failed node Read/write If this bit is set communication with the failed
reconnect control nodes is detected after scan time SW0019 for
port2.By default : ON
S0023 COM3 failed node Read/write If this bit is set communication with the failed
reconnect control nodes is detected after scan time SW0022 for
port3. By default : ON
SW64-S65 Node Status Registers Read only Shows the status of the node, whether node is
for COM1 present or not. Total 2 word Register are mapped
for 32 nodes.
SW66-S79 Node Status Registers Read only Shows the status of the node, whether node is
for COM1 present or not. Total 14 word Register are mapped
for 224 nodes.
SW80-S81 Node Status Registers Read only Shows the status of the node, whether node is
for COM2 present or not. Total 2 word Register are mapped
for 32 nodes.
SW82-S95 Node Status Registers Read only Shows the status of the node, whether node is
for COM2 present or not. Total 14 word Register are mapped
for 224 nodes.
SW96-S111 Node Status Registers Read only Shows the status of the node, whether node is
for COM3 present or not. Total 16 word Register are mapped
for 256 nodes.
