HALT MODE
Feed Watch-dog
Turn OFF all Outputs and
RUN Led
Respond to the monitor
query (if any) on USB.
Stop counting main loop
scan time
Main Loop Start
Set Power On system bit to ‘1’
Feed Watch-dog
Turn ON ERROR Led.
Turn OFF RUN Led.
ERROR MODE
Set the state of output as per ‘ERROR
STATE OUTPUT CONDITION’
(Local, expansion and PWM)
Respond to the monitor
query (if any) on USB.
Stop counting main loop
scan time
Main Loop Start
