Programming Information
99
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
You can allot “ss” (slot number) from “Project Information” docker window; “IO Allocation\Local” section as shown
below:
When you double click on the highlighted slot section; below shown window will appear:
Note: Here you have to allot slots seriallly only and if you tried to allott randomly; it will show an error as “Expansion
Modules for PLC are sequencial hence, previous slot can not be empty”
Double click on each
slot to assign model name
To Next Page
