Reymsa HFC Series - Table A-3: Receiving Flange Type (Double Fan Towers); Figure A-16: Fan Duct Assembly for a Double Fan Tower; Figure A-17: Fan Duct Alignment for a Double Fan Tower

REYMSA COOLING TOWERS, INC.
www.reymsa.com
8
J. Remove fan guard. Then cradle/straddle the fan support with the straps (as shown in gure A-16) so you
can lift the fan duct with a crane and assemble it.
K. Identify each fan duct, they are labeled with a number on the inside of the lower edge. For a correct
installation, this number must match the number on the receiving ange. Now place fan duct 1 on the
correspondent receiving ange on top of the tower (see Figure A-16); make sure the bolt holes and the
marks inside the fan duct and the receiving ange are aligned (Figure A-17). Secure it with the stainless
steel nut and bolt sets supplied by REYMSA. There are two different types of receiving anges, each one
has its own assembly pieces (see Table A-3 to verify the type of receiving anges of your tower).
L. Follow the same instructions to place fan duct 2.
Figure A-17: Fan duct alignment for a double fan tower
Installation
R
E
Y
M
S
A
RECESSED FLANGE EXTERNAL FLANGE
Figure A-16: Fan duct assembly for a double fan tower
ASSEMBLY HOLES
1. 1/2” x 2.5” BOLT
2. 1/2” FLAT WASHER
3. 5/8 HOLE
4. 1/2” INSERT
(FACTORY ASSEMBLED)
ASSEMBLY HOLES
1. 1/2” x 2.5” BOLT
2. 1/2” FLAT WASHER
3. 5/8 HOLE
4. 1/2” FLAT WASHER
5. 1/2” LOCK WASHER
6. 1/2” NUT
Table A-3: Receiving ange type (double
fan towers)
HFC DOUBLE FAN MODELS
RECESSED FLANGE EXTERNAL FLANGE
510 816
612 819
714 822
827
Note: Also applies for low sound fans.
