4003 DERIVATION TIME: 0.0 s
4004 PID DERIV FILTER: 1.0 s
2202 ACCELER TIME 1: 30.0 s
2203 DECELER TIME 1: 30.0 s
Do you want to use Sleep function?: NO
Do you want to continue with low noise set-up? SKIP
Do you want to continue with panel display set-up? CONTINUE
Configure Process Variable 1? YES
3401 SIGNAL1 PARAM: (102) SPEED
3402 SIGNAL1 MIN: 0 rpm
3403 SIGNAL1 MAX: 1000 rpm
3404 OUTPUT1 DSP FORM: (9) DIRECT
3405 OUTPUT1 UNIT: (7) rpm
3406 OUTPUT1 MIN: 0 rpm
3407 OUTPUT1 MAX: 1000 rpm
Configure Process Variable 2? YES
3408 SIGNAL2 PARAM: (128) PID 1 SETPNT
3409 SIGNAL2 MIN: 0.0 °C
3410 SIGNAL2 MAX: 100.0 °C
3411 OUTPUT2 DSP FORM: (9) DIRECT
3412 OUTPUT2 UNIT: (9) °C
3413 OUTPUT2 MIN: 0.0 °C
3414 OUTPUT2 MAX: 100.0 °C
Configure Process Variable 3? YES
3415 SIGNAL3 PARAM: (130) PID 1 FBK
3416 SIGNAL3 MIN: 0.0 °C
3417 SIGNAL3 MAX: 100.0 °C
3418 OUTPUT3 DSP FORM: (9) DIRECT
3419 OUTPUT3 UNIT: (9) °C
3420 OUTPUT3 MIN: 0.0 °C
3421 OUTPUT3 MAX: 100.0 °C
Do you want to continue with timed funcs set-up? SKIP
Do you want to cont. With relay and analog output set-up? SKIP
Do you want to copy parameters to panel? YES
Parameters upload successful OK
Note: Refer to VFD user manual for more information.
