RGBlink CP 3072PRO User Manual

Chapter 1: Your Product
CP 3072PRO User Manual
14
STILL
Enable or disable the STILL function. If select “ON”, user can set the X and Y, or load file
from UDisk.
OSD
Enable or disable the OSD function. If select “ON”, user can delete the OSD, or load file
from UDisk.
BK
The button is lit when enable black function. Black is available for PGM channel.
LOCK
Lock top panel button. The button is lit when the buttons in top panel are locked. Push
the button again, the button light is off, and unlock the top panel.
Indicator
The indicator is on when the output format is SD, HD, RGB, 4K1K, 4K2K or CUST.
Independent Effects Switching Area
11
PGM OUT
1/2 button: Independent effects switching for PGM1 or PGM2.
GROUP: Effects switching for PGM1 or PGM2 at the same time.
OSD Edit Area
12
OSD
: Subtitle rows back button.
: Subtitle rows forward button.
OSD TAKE
Subtitles switch button.
Switch Modes Area
13
CUT
Seamless switching.
TAKE
Seamless switching with effect.
T-BAR
WIPE and mix switching.
