Ricoh Aficio C3000 User Manual

Sending Fax Documents from Computers
245
6
E Select a method of file naming.
To enter a file name manually, select the [Specify file name when saving] check
box. To have the file assigned a name and saved automatically, select the [Au-
tomatically create a new file] check box.
F Click [OK].
G Click [Save] or [Save & Send].
If you select [Automatically create a new file], the image file is assigned a name
and saved under the specified folder.
The file name will be RicHHMMSS.tif (HH: hours, MM: minutes, SS: seconds).
H Enter a file name.
You can also change the folder in this step.
I Click [Save].
The image file is saved in the specified folder.
Note
❒ Single-page documents are saved as single TIFF files, and multiple-page
documents are saved as multiple TIFF files.
To store the fax document on the Document Server
Important
❒ If [Hard Disk Unit] is not selected in [Accessories] on the printer properties dia-
log box, you cannot select [Document Server].
A Click [Send Options].
The [Send Options] tab appears.
B Select the [Send to Document Server] check box, and then enter a user name,
file name, and password.

Ricoh Aficio C3000 Specifications

General

Technology	Laser
Color Output	Color
Max Printing Resolution	1200 x 1200 dpi
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Duplex Printing	Yes
Max Paper Size	A3
Standard Paper Capacity	1, 200 sheets
Standard Memory	512 MB
Maximum Memory	1 GB
Hard Drive Capacity	80 GB
Type	Multifunction Printer
Function	Print, Copy, Scan, Fax
Compatibility	Windows, Mac
Warm-up Time	Less than 60 seconds
First Print Out Time (Black)	Less than 10 seconds
