Envelope types Supported/Not supported
Supported
Supported
Supported
• You can load up to 10 envelopes (72 - 90g/m
2
) in the bypass tray at the same time, without
compressing them. Check the envelopes are not damp, and the top of the stack is not higher than the
limit mark on the side guide.
• When loading envelopes, be sure to unfold the flaps and position them opposite to the paper feed
direction.
• Load type (4) (162 114 mm / C6) (6.38 4.49 in. / C6) envelopes flap down, flap fold against
the side guide.
• Depending on the envelope type, specify an appropriate print image rotation using the printer driver.
For a type (1) - (4) envelope, rotate by specify 180 degrees.
21
