Ricoh Aficio MP C4502 General Settings Guide

Registering Addresses and Users for Facsimile/Scanner Functions
226
7
Locating the SMB folder using Browse Network
This section describes how to locate the SMB folder using Browse Network.
A Press [Browse Network].
The client computers sharing the same network as the machine appear.
If you have already specified your user name and password in steps
G
to
M
on "Registering a SMB Folder", the Network display only lists client comput-
ers you are authorized to access.
B Select a client computer.
Shared folders under it appear.
You can press [Up One Level] to switch between levels.
C Select the folder you want to register, and then Press [OK].
If a Login Screen Appears
This section describes how to log on to the machine if the login screen appears
when you try to access a folder by browsing the network.
If you have not specified folder authentication, or if an incorrect user name or
password has been entered for folder authentication, the login screen appears.
A Enter the login user name, and then press [OK].
Enter the login user name specified for folder authentication.
B Enter the password, and then press [OK].
The path to the selected folder appears.
If a message appears, press [Exit], and then enter the login user name and
password again.

Ricoh Aficio MP C4502 Specifications

General

Print Technology	Laser
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Maximum Scan Resolution	600 dpi
Fax Capability	Optional
Maximum Paper Size	12" x 18"
Memory (Standard)	1.5 GB
Hard Drive	250 GB
Copy Resolution	600 x 600 dpi
Print Speed	45 ppm
Standard Paper Capacity	1, 200 sheets
Scanner Type	Flatbed, ADF
Network Connectivity	Ethernet
Functions	Print, Copy, Scan
Copy Speed	Up to 45 ppm (Black/Color)
Fax Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
