PAPER FEED, TRANSPORT, OUTPUT
SM 6-27 J001/J003
Detailed
Descriptions
6.7 PAPER FEED, TRANSPORT, OUTPUT
6.7.1 OVERVIEW
1. Transport Belt Unit
2. High Voltage Power Supply
3. Paper Cassette
4. Vertical Encoder
5. Vertical Encoder Sensor
6. Vertical Motor
1
2
3
5
4
6
