Ricoh MP 6503 Series User Manual

Tray 1 can hold 8
1
/
2
× 11 paper only. If you want to print on A4 from tray 1, contact your
service representative.
1. Carefully pull out tray 1 until it stops.
CJW105
2. Square the paper and load it print side down.
Do not stack paper over the limit mark.
• Whole tray pulled out
DQA156
• Left half of the tray pulled out
DQA157
3. Carefully push the paper tray fully in.
9. Adding Paper and Toner
148

Ricoh MP 6503 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Hard Disk Drive	320 GB
Power Source	220 - 240 V, 50/60 Hz
Supported Operating Systems	Windows, Mac OS, Linux
Monthly Duty Cycle	300, 000 pages
Type	Multifunction Printer
Print Speed	65 ppm
Connectivity	USB 2.0, Ethernet
Supported Paper Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
First Print Speed	3.2 seconds
Paper Weight	52 - 300 gsm
Memory	2 GB
Scanning Speed	120 ipm
Scan Resolution	600 dpi
