Ricoh MP 6503 Series User Manual

Loading Paper into Trays 2 and 3
In the following example procedure, paper is loaded into tray 2.
• If a paper tray is pushed vigorously when putting it back into place, the position of the tray's side
fences may slip out of place.
• Check the paper edges are aligned at the right side.
• When loading a low number of sheets, be sure not to squeeze the side fences in too tightly. If the
side fences are squeezed too tightly against the paper, the edges may crease, the paper may
misfeed, or if it weighs between 52–59 g/m
2
(14–15 lb. Bond), it may wrinkle.
1. Carefully pull out the paper tray until it stops.
CJW103
2. Square the paper and load it print side down.
Do not stack paper over the limit mark.
DQA154
3. Carefully push the paper tray fully in.
• Various sizes of paper can be loaded in trays 2–3 by adjusting the positions of side fences and
end fence. For details, see "Changing the Paper Size in Paper Trays", Paper Specifications and
Adding Paper.
9. Adding Paper and Toner
150

Ricoh MP 6503 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Hard Disk Drive	320 GB
Power Source	220 - 240 V, 50/60 Hz
Supported Operating Systems	Windows, Mac OS, Linux
Monthly Duty Cycle	300, 000 pages
Type	Multifunction Printer
Print Speed	65 ppm
Connectivity	USB 2.0, Ethernet
Supported Paper Sizes	A3, A4, A5, B4, B5, Legal, Letter, Executive
First Print Speed	3.2 seconds
Paper Weight	52 - 300 gsm
Memory	2 GB
Scanning Speed	120 ipm
Scan Resolution	600 dpi
