Paper Feed Unit (D331)
SM 2-21 D037/D038/D040/D041
Installaion
2.4 PAPER FEED UNIT (D331)
2.4.1 ACCESSORY CHECK
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Paper Feed Unit 1
2 Screw - M4 x 10 4
3 Securing Bracket 2
2.4.2 INSTALLATION PROCEDURE
 Unplug the machine power cord before starting the following procedure.
 The handles of the main machine for lifting must be inserted inside the machine
and locked, unless these handles are used for the installation or relocation of the
main machine.
 You need two or more persons to lift the copier. The copier is highly unstable when
lifted by one person, and may cause human injury or property damage.
To Next Page
