Electrical Components
D331 6
SM
1.3 ELECTRICAL
COMPONENTS
T
urn off the main power switch and unplug the machine before beginning any of
the procedures in this section.
1.3.1
VERTICAL TRANSPORT SENSOR
1.
Open the tray cover [A]
2.
Guide plate [B] (
x 2)
3.
Sensor bracket [C] (
x 1,
x 1)
4.
V
ertical transport sensor [D] (hooks)
909
911
