Shift Tray Unit (D428)
D037/D038/D040/D041 2-40 SM
2.11 SHIFT TRAY UNIT (D428)
2.11.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 Shift Tray Unit 1
2.11.2 INSTALLATION PROCEDURE
 Unplug the copier power cord before starting the following procedure.
 If both the shift tray unit and the 1-bin tray unit are installed in the mainframe at the
same time, install the shift tray unit first. Installing the shift tray unit after the 1-bin
tray unit may be difficult.
1. Remove all tapes.
To Next Page
