Extending Tray 1 to load paper
This section explains how to load paper larger than A4 (297 mm) into the machine.
1. Remove the tray cover.
2. Pull Tray 1 out slowly, and then remove it using both hands.
3. Release the extender locks on both sides of the tray, and then pull out the extender.
Make sure the extender's inner surface and the scale are aligned.
You can adjust the length of the extender in three steps. When using A5 SEF, A4 or letter size
paper, adjust the length to the position indicated by the mark " " in the tray.
Loading Paper
21
