Ricoh SP 310DN

Exterior Covers
SM 4-5 M154/M155/M174/M175/A0A7/M287/M0BB
Replacement
and Adjustment
4.3.2 LEFT COVER
1. Front cover (page 4-3 "Front Cover")
2. Rear cover (page 4-7 "Rear Cover")
3. Remove two screws [A] on the front side of the left cover.
4. Remove a screw [A] on the rear upper side of the left cover.
5. Pull the rear upper part [A] of the left cover to release the hooks.
 The outside of the cover has marks indicating the position of the hooks.
6. Pull the front upper part [A] of the left cover to release the hooks.
