Ricoh SP 310DN

Paper Feed
SM 4-19 M154/M155/M174/M175/A0A7/M287/M0BB
Replacement
and Adjustment
4.5.6 BY-PASS FEED SENSOR
1. Front cover (page 4-3 "Front Cover")
2. Right cover (page 4-8 "Right Cover")
3. By-pass feed sensor [A] (3 hooks,
x 1)
4.5.7 PAPER FEED CLUTCH
1. Drive unit (page 4-37 "Drive Unit")
2. Paper feed clutch [A] ( x 1, x 1, x 1)
