Ricoh WG-6 - USB Power Adapter AC-U1;AC-U2; Rechargeable Battery DB-110

109
6
Appendix
USB Power Adapter AC-U1/AC-U2
Power Supply 100 to 240 VAC (50/60 Hz), 0.2 A
Output 5.0 VDC, 1000 mA
Operating Temperature 10 to 40°C (50 to 104°F)
Dimensions 42.5 mm (W) × 22 mm (H) × 66.5 mm (D) (excluding the power plug)
Weight Approx. 40 g (excluding the power plug)
Rechargeable Battery DB-110
Nominal Voltage 3.6 V
Rated Capacity 1350 mAh, 4.9 Wh
Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -10 to 45°C (14 to 113°F)
Dimensions 39.8 mm (W) × 34.2 mm (H) × 8.5 mm (D)
Weight Approx. 26 g
