Add the following components to the
system:
Standard irrigation unit.
Add the following components to the
irrigation unit:
Draw group;
Irrigation group;
pH dosing group;
EC dosing group;
System pump (HortiJet pump);
Irrigation valves.
Add the following component to the draw
group:
Flow sensor. You can choose from:
Flow sensor; GF15 met
paddle wheel.
Water meter with mechanical
counter for pulse
measurement.
Water meter with analogue
current output for flow
measurement.
Under the draw group, you need to
complete the settings for the flow sensor
or the water meter.
If you have a flow sensor, set the
k-factor (pulse/litre).
If you have a water meter with
pulse measurement, set the
number of litres per pulse.
If you have a water meter with flow
meter, set the flow rate
(litres/hour).
