37
Repair Parts
Parts List for RIDGID 10" Compound Miter Saw
Model No. MS10601
RIDGID parts are available on-line at www.ridgidparts.com
Figure 2
Always order by Part Number - Not by Key Number
* Standard hardware item - may be purchased locally.
WARNING: These items are important to the safety of this tool. Do
not substitute common parts.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
See Fig. 4
See Fig. 3
828647
828343
808275-4
826055-1
828648
817791
828501
827588
826163
823297-2
805553-24
9421621
823612
702204-1
817793
Blade Guard
Assembly
Motor Assembly
Table
Plate Throat
Screw Pan Cr
8-32 x 3/8
Knob Miter
Fence Asm
Arm Extension
Base
Shim Table
Cap Grip
Spring Index
Washer
11/32 x 7/8 x 1/16
Scr Soc Cap
5/16-18 x 5/8
Clamp Extension
* Screw Thumb
1/4-20 x 1/2
Stop Block
Key
No.
Part No. Description
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
805553-6
813056-2
826057
809169-3
9416630
823326
826068
828253
9416187
805553-4
821421-6
See Fig. 3
823314
SP6454
SP6454F
Washer
21/64 x 5/8 x 1/16
* Screw Pan Hd.
5/16-18 x 1-1/4
Pointer
* Screw Pan Hd. Type
“T” 8-32 x 3/8
* Screw Hex Type “T”
5/16-18 x 1
Stop Bevel
Indicator Bevel
Knob Bevel
* Screw Hex Type “T”
5/16-18 x 3/4
Washer
21/64 x 9/16 x 1/16
O-Ring
Pivot Asm.
Wrench Combination
Owners Manual -
English/Spanish
Owners Manual -
French
