39
Repair Parts
Parts List For RIDGID 10" Compound Miter Saw
Model No. MS10601
RIDGID parts are available on-line at www.ridgidparts.com
Figure 3 - Motor Assembly
WARNING: For your safety, this miter saw is specially insulated. To
reduce the risk of electrical shock, fire or injury, use only parts identical
to those identified in the parts list. Reassemble exactly as originally
assembled.
Always order by Part Number — Not by Key Number
* Standard hardware - may be purchased locally
WARNING: These items are important to the safety of this tool. Do
not substitute common parts.
• WARNING: Any attempt to repair or replace electrical parts on this
unit may create a hazard unless repair is done by a qualified service
technician. Repair service is available from authorized RIDGID Ser-
vice Center.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
828736
828720
808380-5
828718
828717
826053
828719
826064
354653
826017
826016
Screw Pan Cr Pt
K60 x 75mm
Handle Carry
* Screw Pan Cr
#8 Plastite
Handle Upper
Actuator Switch
Spring Compression
Handle Lower
Cap Motor Housing
Bumper
Holder Brush
Brush
Key
No.
Part No. Description
12
13
14
15
16
17
18
19
20
21
826453
805549-22
826062
823322
823417
829512-1
828716
826066
828735
803709-1
Screw Pn Hd
10-32 x 2-1/4
*Washer
13/64 x 3/8 x 1/32
Lock Arbor
Spring Arbor Lock
Seal
Motor Asm
Button Lock
• Switch SPDT
• Cord w/Plug
Connector Wire
To Next Page
