41
Repair Parts
Parts List For RIDGID 10" Compound Miter Saw
Model No. MS10601
RIDGID parts are available on-line at www.ridgidparts.com
Figure 4 - Blade Guard Assembly
Always order by Part Number — Not by Key Number
* Standard hardware - may be purchased locally
WARNING: These items are important to the safety of this tool. Do
not substitute common parts.
‡ CAUTION: See mechanical assembly caution below.
• WARNING: Uncontrolled spring release or misinstallation of these
parts may create a hazard unless repair is done by a qualified ser-
vice technician. Repair service is available from authorized
RIDGID Service Center.
CAUTION: Mechanical Assembly, to qualified service technician.
1. Wear approved eye protection when working with coil spring
including spring, arbor lock 823322.
2. Incorrect reassembly of torsion spring 823328 can cause an unsafe
condition because cutting head fails to rise fully to stop, or
because spring fails through over-stress.
3. Improper reassembly of mechanisms controlling movement of
lower guard 829605 can cause an unsafe condition because guard
fails to operate freely as cutting head is moved up and down.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
37429
829653
823300-1
823316-1
821421-3
829654
826481
827498
823303
Dust Elbow
Arm/Guard
Washer Cup
Arbor Asm
Ring “O”
Screw
Screw Lock Set
1/4-20 x 3/8
Bumper
Collar Blade
Key
No.
Part No. Description
10
11
12
13
14
15
16
17
18
827413
823304
829605
820219-1
826026
821521-1
821521
823306-1
828364
Blade Saw Carbide
Screw Blade
‡ Guard Asm Lower
Screw Pan Cr Ty “TT”
1/4-20 x 3/8
Link Actuator
Screw Shoulder
Screw Shoulder
Bearing Cam
Bag Dust
To Next Page
